What is 1050 Aluminum Coil?
1050 aluminum is classified as a commercially pure aluminum alloy, with a minimum 99.5% aluminum content. This high purity level is the source of its most defining characteristics. The coil form means it is supplied as a continuous, wound strip of metal, which is ideal for high-volume manufacturing processes like stamping, rolling, and forming.
Its composition makes it part of the 1xxx series of aluminum alloys, which are known for their excellent corrosion resistance, high electrical and thermal conductivity, and low mechanical strength.
The Technical datas of aluminum coil 1050:
Aluminum Association Designation: 1050
Old ISO Designation: Al 99.5
Common Tempers: O (Annealed), H12, H14, H16, H18, H19, H22, H24, H26
1. Chemical Composition (Weight % - ASTM B491)
The high purity of 1050 aluminum is the source of its key properties.
| Element | Min (%) | Max (%) |
|---|
| Aluminum (Al) | 99.50 | Balance |
| Silicon (Si) | - | 0.25 |
| Iron (Fe) | - | 0.40 |
| Copper (Cu) | - | 0.05 |
| Manganese (Mn) | - | 0.05 |
| Zinc (Zn) | - | 0.07 |
| Titanium (Ti) | - | 0.05 |
| Vanadium (V) | - | 0.05 |
| Other (Each) | - | 0.03 |
| Other (Total) | - | 0.10 |
2. Mechanical Properties
Mechanical properties vary significantly with temper. The following data are typical values based on standards like ASTM B209.
Typical Mechanical Properties at Room Temperature:
| Temper | Tensile Strength (MPa) | Yield Strength (0.2% Offset) (MPa) | Elongation (% in 50mm) | Hardness (Brinell) |
|---|
| O (Annealed) | 60 - 85 | 20 - 35 | 35% - 45% | 18 - 23 HB |
| H14 | 100 - 125 | 85 - 105 | 8% - 14% | 32 - 38 HB |
| H16 | 115 - 140 | 105 - 125 | 6% - 10% | 38 - 44 HB |
| H18 | 130 - 155 | 125 - 145 | 4% - 7% | 44 - 50 HB |
| H19 | 150 - 175 | 145 - 165 | 2% - 4% | ~52 HB |
Note: MPa (Megapascals). 1 MPa ≈ 0.145 ksi.
How to get a reliable 1050 Aluminum Coil Supplier?
When sourcing 1050 aluminum coil, it's essential to partner with a reputable supplier or manufacturer. Key factors to consider are:
Quality Certifications: Look for suppliers with relevant quality management certifications.
Range of Offerings: A good supplier will offer the coil in various tempers (like O - Annealed or H14 - Strain Hardened), widths, thicknesses, and surface finishes.
Customer Service and Technical Support: They should be able to provide technical data sheets and guidance on the best product for your specific application.
Hunan Green House Aluminum Industry Co Ltd is a professional aluminum coil supplier in China more than 10 years, we can be your reliable supplier, welcome to contact us get more details!
